Axiomtek, a world-renowned leader relentlessly devoted to the research, development, and manufacture of innovative, highly efficient, and reliable industrial computer products, proudly introduces the CAPA332, a compact 3.5” embedded single board computer (SBC) powered by Intel® processor N97 or N150. Designed for diverse embedded applications, the CAPA332 combines triple-display capability, flexible DC power input, three M.2 expansion slots, and dual 2.5GbE connectivity in a compact 146 x 104 mm form factor. With its versatile architecture and industrial-grade reliability, the CAPA332 is ideal for medical equipment, industrial automation, smart kiosks, gaming machines, transportation systems, smart retail, edge AI systems, and industrial IoT gateways.
“Modern embedded systems need to balance performance, flexibility, and long-term usability. The CAPA332 gives system integrators greater flexibility in display selection, power design, and system expansion. Its compact 3.5-inch form factor and versatile I/O architecture make it easier to adapt the platform to diverse embedded applications while simplifying system integration.”
— Michelle Mi, Product Manager of the EDS Division, Axiomtek
More Display Freedom, Fewer Design Constraints
The CAPA332 supports up to three independent displays with five display interface options, including HDMI 1.4, DisplayPort, dual LVDS, and eDP. This comprehensive display support gives system integrators greater flexibility to work with both legacy and modern display technologies, without requiring additional converter boards. This enables customers to reuse existing display platforms, simplify system integration, and shorten development cycles.
Power Flexibility for Diverse System Designs
Supporting 12V and 19 to 24V DC input, with an optional 12V-only configuration, the CAPA332 accommodates different power infrastructures and application requirements. The optional 12V-only design also provides a cost-optimized configuration for volume projects, helping system integrators align the power architecture with their deployment needs while reducing integration effort and overall project costs.
Built to Expand as Your Applications Evolve
The CAPA332 integrates three M.2 expansion slots—Key B, Key E, and Key M—to support wireless connectivity, high-speed storage, and application-specific expansion. This flexible architecture enables integration of 5G, Wi-Fi, Bluetooth, and NVMe storage, allowing system integrators to adapt the platform to different application requirements.
Compact Today, Ready for What’s Next
Measuring only 146 x 104 mm, the CAPA332 delivers extensive I/O and expansion capabilities in a compact form factor. In addition to dual Intel® I226-V 2.5GbE ports, the board provides USB, SATA, audio, RS-232/422/485, GPIO, and onboard TPM 2.0 for a broad range of embedded system requirements. Its operating temperature range of -20°C to +70°C further supports reliable deployment in industrial environments.
With power-efficient Intel® processors and support for both legacy and modern display interfaces, the CAPA332 can help reduce energy consumption, preserve existing hardware investments, and minimize unnecessary replacement and electronic waste. Its scalable expansion architecture also helps extend system lifecycle as application requirements evolve.
The CAPA332 is now available. For more product information or customization services, please visit www.axiomtek.com or contact one of our sales representatives at info@axiomtek.com.tw.
Advanced Features of CAPA332
- Intel® processor N97/N150
- DDR5-4800 SO-DIMM for up to 32GB
- 2 2.5GbE ports
- 3 M.2 expansion slots
