GOT315C-ADL-WCD

Status : Available

15.6" FHD Fanless Touch Panel Computer with LGA1700 Socket 14th/13th/12th Gen Intel® Core™ i9/i7/i5/i3 or Pentium® Processor

Datasheet
Datasheet (PDF)
Add to Compare
Add to Compare
Get a Quote
Get a Quote
GOT315C-ADL-WCD
GOT315C-ADL-WCD
GOT315C-ADL-WCD
GOT315C-ADL-WCD
Fanless

Fanless

IP65 Rating

IP65 Rating

PCAP

PCAP

TPM

TPM

Wide Temperature

Wide Temperature

  • Features
  • Specifications
  • Ordering Information
  • Download

Features

  • 15.6" FHD TFT LCD with 450 nits of brightness
  • 10-point PCAP multi-touch panel
  • Supports one 2.5" SATA HDD/SSD
  • Supports 2 HDMI outputs for second display
  • Supports WLAN module and antenna (optional)
  • Supports 4 USB and 2 COM ports
  • Flexible I/O window with support for COM3, and DIO (optional)
  • Supports panel mount, VESA mount, desktop stand, and wall mount
  • Wide temperature range of -10°C to +50°C

Specifications

LCD Panel
  • 15.6" FHD TFT LCD
  • 450 nits
  • 1920 x 1080
CPU
  • LGA1700 socket 14th/13th/12th Gen Intel® Core™ i9/i7/i5/i3 or Pentium® processor (up to 35W)
Chipset
  • Intel® H610
System Memory
  • 1 x 262-pin DDR5 5600 MHz SO-DIMM, up to 48GB
BIOS
  • AMI
COM
  • 1 x RS-232
USB
  • 2 x USB 3.2 Gen 1 (Type A)
  • 2 x USB 2.0 (Type A)
Ethernet
  • 1 x RJ-45 for GbE (Intel® I219-V)
  • 1 x RJ-45 for 2.5GbE (Intel® I226-V)
Display
  • 2 x HDMI 1.4b
Audio
  • 1 x Line-out
Storage
  • 1 x 2.5" SATA HDD (WT)/SSD (7 mm and 9.5 mm height, removable)
Expansion
  • 1 x M.2 Key E 2230 with PCIe x1 and USB 2.0
  • 1 x PCI Express Mini Card slot (USB + PCIe signal + nano SIM slot "LTE")
  • 1 x flexible I/O window, supporting COM3, and DIO (onboard optional)
TPM
  • TPM 2.0
Others
  • 1 x Phoenix-type connector for DC power input
  • 1 x switch for power on/off (ATX)
  • 1 x remote power switch
  • 1 x grounding hole
Touchscreen
  • Projected capacitive touch
Front Bezel
  • IP65, NEMA 4 rugged protection, metal front bezel
Power Supply
  • 10 to 36V DC-in (typical 12/24VDC) via terminal block
Power Consumption
  • 135W
Watchdog Timer
  • 255 levels, 0 to 255 sec.
Operating Temperature
  • -10°C to +50°C (+14°F to +122°F) (35W CPU/SSD)
Relative Humidity
  • 10% to 95% @ +40°C; non-condensing
Shock & Vibration
  • 1 Grms, 5 to 500 Hz, random, operating (with SSD)
Dimensions<br>(W x D x H)
  • 533 x 222 x 463 mm (20.98" x 8.74" x 18.22")
Weight (net/gross)
  • 6.61 kg (14.58 Ibs)/8.65 kg (19.07 Ibs)
Certifications
  • CE Class A, IEC/EN 61000-6-4, and IEC/EN 61000-6-2
  • FCC 47 CFR Part 15 Subpart B (Class A)
  • UKCA
  • RoHS standard
EOS
  • Win 11, Win 11 IoT, and Linux
Mounting
  • Panel mount
  • VESA mount
  • Desktop stand
  • Wall mount

Ordering Information

  • GOT315C-ADL-WCD (P/N-E22B315C00)
    15.6" FHD TFT fanless touch panel computer with LGA1700 socket 14th/13th/12th Gen Intel® Core™ i9/i7/i5/i3 or Pentium® processor (up to 35W), 10-point projected capacitive multi-touch screen, and 10 to 36V terminal block connector
  • 4G LTE kit
  • Wi-Fi kit
  • 594K6220210E
    Remote power cable, L= 720 mm
  • E29R131114
    Wall mount kit
  • 50906A24000E
    Adapter 24V 230W FSP230-AAAN3 WIRE FSP
  • E29R131112
    Panel mount kit + bag (E)
  • E392902103
    AX92902 + AX93287 full-size PCI Express Mini module with GbE
  • E392903102
    AX92903 full-size PCI Express Mini module with CAN bus
  • E392918103
    AX92918 full-size PCI Express Mini module with 2GbE
