| CPU |
- 14th/13th/12th gen Intel® Core™ processor, up to 65W
|
| Chipset |
|
| System Memory |
- 262-pin DDR5 4800 non-ECC SO-DIMM, up to 96GB
|
| BIOS |
|
| COM |
- 1 x RS-232/422/485 (default RS-232)
- More COM ports are available from extension I/O modules
|
| USB |
- Intel® H610E:
- 2 x USB 3.2 Gen 2 (10G) Type-A
- 2 x USB 3.2 Gen 1 (5G) Type-A
- 2 x USB 2.0
- Intel® Q670E:
- 6 x USB 3.2 Gen 2 (10G) Type-A
- 1 x USB 2.0 (internal, up to 30 mm) 180D Type-A
|
| Ethernet |
- 1 x 2.5GbE LAN (Intel® I226-V)
- 1 x 1GbE LAN (Intel® 1219-LM); with Intel AMT (Q670)
- More LAN ports are available from extension I/O modules
|
| Display |
- 1 x DisplayPort++ with support for 4096 x 2160 resolution
- 1 x HDMI with support for 4096 x 2160 resolution
- 1 x DVI-D with support for 1920 x 1200 resolution
|
| Digital I/O |
- Available from extension I/O modules
|
| Audio |
- 1 x 3.5mm jack for Mic-in and Line-out
|
| Storage |
- Intel® H610E:
- 2 x 2.5" HDD/SSD bay (7/9.5/15 mm height)
- Intel® Q670E:
- 2 x 2.5" HDD/SSD bay (7/9.5/15 mm height)
- 1 x M.2 Key M 2280 socket (PCIe x4 Gen4)
|
| Expansion |
- UP to 230W power for add-in card, 1 x USB 2.0 (180D Type-A)
- 1 x PCIe x16 Gen 4 + 1 x PCIe x8 (x4 signal) Gen 4
- 1 x full-size PCI Express Mini Card slot (USB & PCIe interface) with SIM slot
|
| Others |
- TPM 2.0
- 1 x HDD/SSD access LED
- 3 x User's LED
- 1 x Switch for power on/off with LED (default ATX)
|
| Power |
- Input: 18 to 36 VDC
- 1 x Switch for power on/off with LED (default ATX)
- 1 x 4-pin TB for DC input
- 1 x 4-pin TB for ignition control, remote power and remote LED
|
| Construction |
- Aluminum extrusion heavy-duty cold-rolled steel
|
| Vibration |
- IEC 60068-2-64 (with SSD: 1Grms, random, 5 to 500 Hz)
- MIL-STD-810H, Method 514.8, Category 20
|
| Shock |
- IEC 60068-2-27 (with SSD: 50G, half sine, 11 ms duration)
- MIL-STD-810H, Method 516.8, Procedure I
|
| Operating Temperature |
- -20°C to +60°C with 14th/13th/12th Gen Intel® Core™ processor and industrial wide-temp SSD, 0.7 m/s airflow
|
| IP Rating |
|
| Relative Humidity |
- 10% to 90% relative humidity, non-condensing
|
Dimensions
(W x H x D) |
- 170 x 192 x 260 mm (6.69" x 3.62" x 10.24")
|
| Weight (net/gross) |
- 5.1 kg (11.24 lb)/6.2 kg (13.67lb)
|
| Software Support |
|
| EOS Support |
- Win 10, Win 11, Win 10 IoT, Win 11 IoT, and Linux OS
|
| Certifications |
- CE (EN 61000-6-4/EN 61000-6-2)
- FCC
|
