| LCD Panel |
- 12.1" WXGA TFT LCD with LED backlight
- 400 nits
- 1280 x 800 pixels
|
| CPU |
- Intel® processor N150 4 cores (up to 3.6 GHz)
|
| Chipset |
|
| System Memory |
- Onboard 8GB LPDDR5 (16GB by option)
|
| BIOS |
|
| COM |
- 1 x RS-232/422/485
- 1 x RS-232
|
| USB |
- 2 x USB 3.2 Gen 2
- 2 x USB 2.0
- 1 x USB Type-C (Gen 2x1, 10Gbps, 5V/3A output, DP 1.4)
|
| Ethernet |
- 2 x 2.5GbE Ethernet (I226-V, supports UEFI PXE boot and LAN wake-up, w/o TSN)
|
| Display |
|
| Audio |
|
| Storage |
- 1 x M.2 Key M 2242/2280 (PCIe Gen 3 x2 NVMe)
- 1 x mSATA; supported via full-size mini PCIe slot (shared)
- 1 x removable 2.5" SATA SSD
|
| Expansion |
- 1 x M.2 E Key 2230 for wireless (PCIe & USB 2.0)
- 1 x full-size mini PCIe slot (PCIe/SATA +USB)
- 1 x Nano SIM card slot
- 1 x flexible I/O window (optional)
|
| Others |
- TPM 2.0
- 1 x power input via 3-pin terminal block connector
- 1 x power button
- 1 x AT/ATX DIP switch
|
| Touchscreen |
- Projected capacitive multi-touch
|
| Front Bezel |
- IP65, NEMA 4 rugged protection, metal front bezel
|
| Power Supply |
- 9 to 36 VDC (typ. 12/24 VDC)
|
| Power Comsumption |
- 50W (Measured under full system loading with LCD on and peripherals connected)
|
| Watchdog Timer |
- 65536 levels, 0 to 65535 sec.
|
| Operating Temperature |
- -10°C to +50°C (+14°F to +122°F)
|
| Relative Humidity |
- 10% to 95% @ +40°C, non-condensing
|
| Shock/Vibration |
- Vibration (operating): MIL-STD-810H, Method 514.8, Category 20, and Figure 514.8C-2
- Shock (operating): MIL-STD-810H, Method 516.8, Table 516.8-I, and Procedure I
|
Dimensions
(W x D x H) |
- 312.3 x 56.6 x 227.9 mm (12.3" x 2.22" x 8.97")
|
| Weight (net/gross) |
- 4.03 kg (8.88 lbs)/5.73 kg (12.63 lbs)
|
| Certifications |
- CE Class A, IEC/EN 61000-6-4, IEC/EN 61000-6-2 (heavy industrial grade)
- UKCA
- FCC 47 CFR Part 15 Subpart B (Class A)
- RoHS standard
|
| EOS |
- Windows® 11, Windows®11 IoT, and Linux
|
| Mounting |
- Panel mount kit
- Wall mount kit
- Stand kit
|
