| CPU |
- AMD Ryzen™ Embedded P100 Series SoC "Zen 5" APU, 28W (15W to 54W)
- P185, 12 Core (4 Classic / 8 Dense, 24MB, L3), 5.1 GHz
- P174, 10 Core (4 Classic / 6 Dense, 24MB, L3), 5.0 GHz
- P164, 8 Core (3 Classic / 5 Dense, 16MB, L3), 5.0 GHz
- P132, 6 Core (2 Classic / 4 Dense, 8MB, L3), 4.5 GHz
- P121, 4 Core (1 Classic / 3 Dense, 8MB, L3), 4.4 GHz
|
| Chipset |
|
| System Memory |
- 2 x 262-pin DDR5-5600 SO-DIMM, up to 96GB, ECC supported
|
| BIOS |
- AMI UEFI BIOS
- Trusted Boot (BIOS Secure Boot) with Secure Hash and Public Key Algorithms
|
| Watchdog Timer |
|
| USB |
- 1 x USB 3.2 Gen 1 x1 (Gbps)
- 1 x USB 3.2 Gen 1 x1 (5 Gbps) Type-A
- 3 x USB 2.0
- 2 x USB 2.0 box header
|
| Serial Interface |
- 2 x full RS-232 DB9 ports (COM1 supports RS-232/422/485)
|
| Ethernet |
- 2 x GbE (1GbE default, 2.5GbE by option)
|
| Audio |
- Realtek ALC888S, High Definition Audio (HD Audio)
- 3.5 mm audio jacks: Line-In, Line-Out
|
| Display |
- 4 x DP++, up to 4 independent 4K @ 120Hz displays
|
| GPIO |
- 1 x 8-bit GPIO box header
|
| Expansion |
- 1 x PCIe x16 (PCIe x8 signal)
- 1 x M.2 Key E (2230, PCIe x1)
- 2 x PCIe golden finger expansion for Axiomtek Gaming
- I/O module
|
| Storage |
- 1 x M.2 Key M (2280, PCIe x4) NVMe support
- 2 x SATA 3.0 (support pin-7 power SATA DOM)
|
| Security |
- Onboard TPM 2.0 and fTPM supported
- RSA2048 and AES256 hybrid encryption
|
| Power Input |
|
| Dimensions |
|
| Operating Temperature |
- 0°C to +60°C (+32°F to +140°F)
|
| Humidity |
- 10% to 90% relative humidity, non-condensing
|
| OS |
- Windows® 11 IoT Enterprise, Linux 26.04
|
| Software |
- Optional SAS 6.02 COM port driver (via gaming I/O module)
|
