| CPU |
- AMD Ryzen™ Embedded V1000 series
- V1202B / 2.3 GHz (12-25W)
- V1605B / 2.0 GHz (12-25W)
- V1756B / 3.25 GHz (35-54W)
- V1807B / 3.35 GHz (35-54W)
|
| Chipset |
|
| System Memory |
- 2 x Dual-channel DDR4-2400/3200 non-ECC/ECC SO-DIMM, up to 64GB
|
| BIOS |
|
| Serial |
|
| USB |
|
| Ethernet |
- 1 x 10/100/1000 Mbps Ethernet (Intel® i210)
|
| Display |
- 1 x VGA; 1920 x 1200 @60Hz
- 1 x LVDS dual-channel 18/24-bit or eDP 1.3 (optional)
- 2 x DDI (HDMI 1.4, DVI, DisplayPort 1.2)
|
| GPIO |
|
| Audio |
- HD link interface to baseboard for Codec
|
| Storage |
|
| Expansion |
- 7 x PCIe x1 via PCIe bridge
|
| Others |
|
| Battery |
|
| Power Input |
- ATX: +12V, +5VSB
- AT: +12V
- Wide range input: +8V to +20V
|
| Watchdog Timer |
- 65536 levels, 0 to 65535 sec.
|
| Hardware Monitoring |
|
| Operating Temperature |
- -20°C to +60°C (-4°F to +140°F)
|
| Relative Humidity |
- 10% - 95% relative humidity, non-condensing
|
| Vibration |
|
| Dimensions |
|
| Board Thickness |
|
| Certifications |
|
