| CPU |
- COM Express™ Type 6 module
|
| Chipset |
|
| System Memory |
|
| BIOS |
|
| Serial |
|
| USB |
- 4 x USB 3.2 Gen 2 (one USB 3.2 is alternative with M.2 key B USB 3.2)
|
| Ethernet |
- 1 x RJ-45 for 10/100/1000/2500 Mbps
|
| Display |
- 1 x LVDS; 18/24-bit dual channel
- 1 x eDP
- 1 x VGA
- 1 x HDMI
- 2 x DisplayPort
|
| GPIO |
|
| Audio |
|
| Storage |
- 4 x SATA-600
- 1 x SD card socket
|
| Expansion |
- 1 x PCIe x16
- 1 x PCIe x4
- 1 x M.2 Key E 2230 (PCIe x1, 1 x USB 2.0)
- 1 x M.2 Key B 2242 (PCIe x1, USB 2.0 / optional USB 3.2 with USB-A, optional SATA with SATA port)
- 1 x M.2 Key M 2280 (PCIe x4)
- 2 x PCIe x1
|
| Others |
- 1 x LPC interface
- 1 x SPI interface
- 1 x I2C
- Port 80 display dual 7 segments port
- Smart Battery (with AX98252)
|
| Battery |
|
| Power Input |
|
| Watchdog Timer |
|
| Hardware Monitoring |
|
| Operating Temperature |
- -40°C to +85°C (-40°F to +185°F)
|
| Relative Humidity |
- 10% to 95% relative humidity, non-condensing
|
| Vibration |
|
| Dimensions |
|
| Board Thickness |
|
| Certifications |
|
