| CPU |
- Intel® Core™ i5-8365UE, 1.6 GHz
- Intel® Celeron® 4305UE, 2.0 GHz
|
| Chipset |
|
| System Memory |
- 1 x 260-pin DDR4-2400 SO-DIMM, up to 32GB
|
| BIOS |
|
| COM |
|
| USB |
- 2 x USB 2.0
- 2 x USB 3.1 Gen2
|
| Ethernet/PoE |
- 2 x 10/100/1000 Mbps Ethernet (Intel® I219-LM, Intel® I210-AT)
|
| Display |
- 1 x DisplayPort++
- 1 x HDMI (lockable)
|
| Digital I/O |
|
| Audio |
|
| Storage |
- 1 x 2.5" SATA HDD drive bay (max. up 9.5 mm height)
|
| Expansion |
- 1 x M.2 Key E 2230 (for Wi-Fi)
|
| Others |
- 1 x ATX power switch
- 1 x AT/ATX quick switch
- 1 x Screw type VDC power input connector
- 2 x Antenna opening
- 1 x Phoenix type VDC power input connector
|
| Power |
|
| Watchdog Timer |
- 65535 levels, 1 to 65536 sec.
|
| Construction |
- Aluminum extrusion and heavy-duty steel, IP40
|
| Operating Temperature |
- -10°C to +50°C (+14°F to +122°F) with 0.7 m/s air flow (with W.T. SSD/DRAM)
|
| Relative Humidity |
- 10% to 90%, non-condensing
|
| Vibration |
- IEC 60068-2-64 (with SSD: 3Grms STD, random, 5 to 500 Hz, 1 hr/axis)
|
| Shock |
- IEC 60068-2-27 (with SSD: 50G, half sine, 11 ms duration)
|
Dimensions
(W x D x H) |
- 141.6 x 106 x 73 mm (5.57" x 4.17" x 2.87")
|
| Weight (net/gross) |
- 1.1 kg (2.43 lb)/1.8 kg (3.96 lb)
|
| Certifications |
|
| EOS Support |
|
| Software Support |
|
| Mounting |
- DIN-Rail kit
- VESA mount kit
- Wall mount kit
|
