| CPU |
- Intel® Core™ Ultra processors family (Meteor Lake U/H)
|
| Chipset |
|
| System Memory |
- 2 x DDR5-5600 SO-DIMM, up to 96GB
|
| BIOS |
|
| Serial |
|
| USB |
- 4 x USB 3.2 Gen2
- 8 x USB 2.0
|
| Ethernet |
- 1 x 10/100/1000/2500 Mbps Ethernet with Intel® I226, supporting Wake-on-LAN and PXE Boot ROM
|
| Display |
- Quad simultaneous independent displays are supported:
- 1 x LVDS; 18/24-bit single/dual channel (optional eDP 1.4b HBR3: 5120 x 3200@60Hz)
- 3 x DDI with configurable HDMI 2.1 (4096 x 2304 @60Hz) and DisplayPort 2.1 HBR3 (4096 x 2304 @60Hz)
|
| GPIO |
|
| Audio |
|
| Storage |
- 2 x SATA Gen3
- NVMe for up to 1TB
|
| Expansion |
- Up to 1 x PCIe Gen4 x8 (PEG) + 8 x PCIe Gen3 x1 (HSIO)
|
| Others |
|
| Battery |
|
| Power Input |
- ATX: Vin and VSB
- AT: Vin
- Vin: 8.5 to 20V
- VSB: 4.75 to 5.25V
- RTC battery: 2.0 to 3.3V with support for AT and ATX modes
|
| Watchdog Timer |
- 65536 levels, 0 to 65535 sec.
|
| Hardware Monitoring |
|
| Operating Temperature |
- Standard: 0°C to +60°C (+32°F to +140°F) with a system thermal solution
- Extended range available upon request: -40°C to +85°C (-40°F to +185°F) with a system thermal solution
|
| Relative Humidity |
- 10% to 95% relative humidity, non-condensing
|
| Vibration |
|
| Dimensions |
|
| Board Thickness |
|
| Certifications |
|
