| CPU |
- LGA4677 socket (socket E) 5th/4th gen Intel® Xeon® Scalable processors (Platinum, Gold, Silver, and Bronze), up to 350W TDP
|
| Chipset |
|
| System Memory |
- 8 x DDR5-5600 R-DIMM ECC, up to 512GB memory
|
| BIOS |
|
| COM |
- 1 x Rear I/O COM (RS-232 DB9)
- 1 x Internal COM (RS-232)
|
| USB |
- 4 x USB 3.2 Gen1
- 2 x Internal USB 3.2 Gen1
- 2 x Internal USB 2.0
- 1 x Internal USB 2.0 Type-A (for license dongle)
|
| Ethernet |
- 2 x 10/100/1000 Mbps Ethernet (Intel® I210-AT)
- 1 x Dedicated IPMI LAN port (Realtek RTL8211F)
|
| Display |
|
| Digital I/O |
|
| Audio |
- HD audio interface (2x8 pin header)
|
| Storage |
- 1 x NVMe M.2 Key M 2280 (PCIe Gen5 x4)
- 1 x MCIO (PCIe Gen5 x8) for 2 x NVMe SSD
- 6 x SATA-600 with RAID 0/1/5/10
|
| Expansion |
- Slot 1 & 2: PCIe x16 (1 x Gen5 x16 or 2 x Gen5 x8 via jumper setting)
- Slots 3, 5, & 7: PCIe x16 (Gen5 x16 link)
- Slot 6: NVMe M.2 Key M 2280 (PCIe Gen4 x4)
|
| Others |
- SMBus
- IPMI 2.0
- Redfish API
- 1 x PS/2 keyboard and mouse
|
| Battery |
|
| TPM |
|
| Watchdog Timer |
- 255 levels, 1 to 255 sec.
|
| Hardware Monitoring |
|
| Operating Temperature |
- 0°C to +60°C (+32°F to +140°F)
|
| Relative Humidity |
- 10% to 95% relative humidity at 40°C, non-condensing
|
| Dimensions |
|
| Board Thickness |
|
| Certifications |
|
