| CPU |
- Intel® processor N97/Core™ i3-N305 processor
|
| Chipset |
|
| System Memory |
- 8GB LPDDR5 onboard (16GB optional)
|
| BIOS |
|
| COM |
|
| USB |
|
| Ethernet |
- 2 x 10/100/1000/2500 Mbps Ethernet (Intel® I225)
|
| Display |
|
| Digital I/O |
- 4-channel in/out programmable
|
| Audio |
- HD Audio link via pin header
|
| Storage |
- 1 x M.2 Key B 2242 (PCIe x2/USB 2.0)
- 1 x PCIe NVMe SSD onboard, up to 512GB (optional)
|
| Expansion |
- 1 x M.2 Key E 2230 (PCIe x1/USB 2.0)
- 1 x M.2 Key B 3042/3052 (PCIe x1/USB 3.2), optional
|
| Others |
|
| Battery |
|
| Power Input |
- 2 x 2-pin connector
- +12V DC-in only
- AT auto power on function supported
|
| Power Requirements |
|
| Watchdog Timer |
- 255 levels, 0 to 255 sec.
|
| Hardware Monitoring |
|
| Operating Temperature |
- -20°C to +70°C (-4°F to +140°F)
|
| Relative Humidity |
- 10% to 95% relative humidity, non-condensing
|
| Dimensions |
|
| Board Thickness |
|
| Certifications |
|
| Industrial Chassis |
- APC238-N97-8GB (P/N-E27P238100): APC238 with Intel® processer N97, 8GB LPDDR5, 64GB Key B NvME and 12V/60W adapter
- SBC Option: PICO338-N97-8GB
- I/O: 2 x USB 3.2, 2 x 2.5 GbE LAN, 1 x HDMI, 1 x 12V DC Jack, 1 x Power button
- Dimensions (W x D x H): 161 mm (6.34") x 100 mm (3.94") x 50.6 mm (1.99")
- Operating Temperature: -20°C to +50°C (-4°F to +122°F)
|
