| CPU |
- Intel® Core™ i7-8665UE/i5-8365UE processor (Whiskey Lake-U) with TDP 15W
|
| Chipset |
|
| System Memory |
- 2 x 260-pin DDR4-2666 non-ECC SO-DIMM, up to 64GB
|
| Graphics |
- Intel® UHD Graphics 620
- Supports Gfx - DX12.0, OCL2.0, OGL4.3
|
| BIOS |
|
| COM |
|
| USB |
|
| Ethernet |
- 2 x 10/100/1000 Mbps Ethernet (Intel® i210-IT & Intel® i219-LM)
|
| Display |
- 1 x HDMI 1.4
- 1 x DisplayPort 1.2
|
| Storage |
- 1 x 2.5" SATAIII SSD
- 1 x M.2 Key M 2280 NVMe SSD slot
|
| Expansion |
- 1 x Full-size PCI Express Mini Card slot (USB + PCIe signal)
|
| Others |
- 1 x Power on/off button
- 1 x DC power input connector
- 2 x SMA-type antenna connector
|
| TPM |
|
| Power Supply |
|
| Watchdog Timer |
- 65535 levels, 1 to 65535 sec.
|
| Operating Temperature |
- 0°C to +40°C (+32°F to +104°F)
|
| Relative Humidity |
- 10% - 90%, non-condensing
|
| Vibration Endurance |
- 3Grms STD, random, 5 to 500 Hz, 1 hr/axis
|
| Dimensions (W x D x H) |
- 250 x 220 x 60mm (9.8" x 8.66" x 2.36")
|
| Weight (net/gross) |
|
| EOS Support |
|
| Certifications |
- CE, FCC
- IEC-60601 Compliance
|
