Form Factor |
|
CPU |
- Intel® Xeon® W-1200 or 10th gen Intel® Core™ i9/i7/i5/i3 processor
|
Chipset |
|
System Memory |
- 4 x DDR4 2933MHz ECC (By CPU) or non-ECC UDIMM, up to 128GB
|
BIOS |
|
Ethernet |
- 8 x GbE RJ-45
- 2 x SFP (Intel® i350)
- 2 x NIC modules through AX98621 I/O board (optional)
|
LAN Bypass |
|
LAN Module |
- 2 x NIC modules through AX98621 I/O board (optional)
|
Storage |
- 2 x 2.5" SATA HDD/SSD bays
- 1 x M.2 2242 Key B slot (SATA)
|
Expansion |
- 1 x PCIe x8 through AX96708 riser card (optional)
- 1 x M.2 Key E 2230 (PCIe x1)
- 1 x M.2 Key M 2242/2280 (PCIe x4) through AX98621 I/O board (optional)
- 1 x PCIe Mini Card slot (PCIe x1 in default, SATA by BOM option)
- 1 x Nano SIM socket
|
I/O Interface |
- 1 x Console (RJ-45)
- 2 x USB 3.0
- 1 x LCM with 4 keypads
- 1 x VGA (optional)
|
Power Supply |
- 300W single power supply
- 400W 1U redundant power supply
|
LCM Module |
|
Watchdog Timer |
- 255 stepping for system reset
- 8 stepping for LAN Bypass
|
Operating Temperature |
- 0°C to +40°C (+32°F to +104°F)
|
Dimensions (H x W x D) |
- 44 x 430 x 450 mm (1.73" x 16.93" x 17.7")
|
Weight (net/gross) |
- 6.0 kg/9.5 kg (single power)
- 7.3 kg/10.8 kg (redundant power)
|
OS |
|
Certifications |
|
Others |
- Onboard TPM 2.0
- BMC AST2500, IPMI 2.0 (optional)
|
