| CPU |
- Intel® Core™ i7-7600U 2C@2.8 GHz, TDP: 15W
- Intel® Core™ i5-7300U 2C@2.6 GHz, TDP: 15W
- Intel® Core™ i3-7100U 2C@2.4 GHz, TDP: 15W
- Intel® Celeron® 3965U 2C@2.2 GHz, TDP: 15W
|
| Chipset |
|
| System Memory |
- 1 x DDR4-2133 SO-DIMM, up to 16GB
|
| BIOS |
|
| COM |
- 1 x DB9 serial console or RS-232/422/485
|
| USB |
- 1 x M12 A-code USB 2.0 (with 2 x USB 2.0)
- 4 x USB 3.0
|
| PoE |
|
| Ethernet |
- 2 x RJ-45 10/100/1000 Mbps (Intel® i210-IT)
|
| Display |
- 1 x HDMI 4K x 2K @24Hz
- 1 x VGA (up to 1920 x 1200 @60Hz)
|
| CANbus |
|
| Digital I/O |
- 1 x Terminal block isolated DIO 4-in/4-out (isolation voltage: 2 kV)
|
| Audio |
|
| Storage |
- 1 x Swappable 2.5" SATA drive (9.5 mm height)
- 1 x CFast™
|
| Expansion |
- 2 x Full-size Rev.1.2 PCI Express Mini Card slot (USB/PCIe)
- 1 x PIM (Plug-in I/O Module) slot
- 1 x External SIM card slot
|
| Others |
- TPM 2.0
- 1 x Reset button
- 4 x Antenna opening
|
| Power Supply |
- 1 x M12, 24 to 110 VDC (S2 optional)
|
| Power Consumption |
- 24-110V@2.9-0.55A (with PIM901T)
|
| Watchdog Timer |
- 255 levels, 1 to 255 sec.
|
| Construction |
- Aluminum extrusion and heavy-duty steel, IP30
|
| Operating Temperature |
- -40°C to +70°C (-40°F to +158°F) with W.T. peripheral
|
| Relative Humidity |
- 0% to 95%, non-condensing
|
| Vibration |
- 3 Grms w/ SSD & wall mount (5 to 500Hz, X/Y/Z direction; random, operating)
- 2 Grms w/ SSD & DIN-rail (5 to 500Hz, X/Y/Z direction; random, operating)
- MIL-STD-810G, Method 514.6C-VI Category 4 compliant (for wall mount)
- EN 50155 EN 61373 category 1 class B
|
| Shock |
- EN 50155 EN (IEC) 61373 category 1 class B, half-sine pulse, 5g, 30ms (longitudinal direction), 3g, 30ms (vertical/transverse direction)
|
Dimensions
(W x D x H) |
- 119.8 x 124.8 x 155 mm (4.72" x 4.91" x 6.1")
|
| Weight (net/gross) |
|
| Certifications |
- CE, LVD, FCC, and EN 50155 certified
- EN 50124 compliant
|
| EOS Support |
- Windows® 10 64-bit, Linux
|
| Software Support |
|
| Mounting |
- Wall mount & DIN-rail (optional)
|
