| CPU |
- LGA1151 socket 9th/8th Gen Intel® Core™ i7/i5/i3, Pentium® & Celeron® processor (TDP 35W)
|
| Chipset |
|
| System Memory |
- 1 x 260-pin DDR4-2666 SO-DIMM, up to 16GB
|
| BIOS |
|
| COM |
|
| USB |
|
| Ethernet |
- 1 x 10/100/1000 Mbps Ethernet (Intel® I210-AT)
- 1 x 10/100/1000 Mbps Ethernet ( Intel® i219-LM)
- 1 x 10/100/1000 Mbps Ethernet (Intel® I210-AT; optional)
|
| Display |
- 1 x HDMI
- 1 x LVDS; 18/24-bit single/dual channel
- 1 x DisplayPort
|
| Digital I/O |
- 8-channel in/out programmed
|
| Audio |
|
| Storage |
- 2 x SATA-600
- 1 x mSATA (optional)
|
| Expansion |
- 1 x PCI Express Mini Card slot
- 1 x USB, 1 x PCIe x1, 1 x LPC, 1 x SMBus through a ZIO connector
|
| Others |
|
| Battery |
|
| Power Input |
- 2 x 2-pin connector
- +12V DC-in only
- AT Auto Power On function supported
|
| Power Requirements |
|
| Watchdog Timer |
- 255 levels, 1 to 255 sec.
|
| Hardware Monitoring |
|
| Operating Temperature |
- -20°C to +60°C (-4°F to 140°F)
|
| Relative Humidity |
- 10% to 95% relative humidity, non-condensing
|
| Dimensions |
|
| Board Thickness |
|
| Certifications |
|
| Industrial Chassis |
|
