Features
- CE, FCC and E-mark certified
- Intel Atom® x5-E3930 processor (Apollo Lake-I)
- Extreme cost-effective with fanless and cableless design
- Wide operating temperature range from -40°C to +70°C
- Supports typical 12 and 24V DC in-vehicle power input
- Smart Ignition for power on/off schedule, vehicle battery protection and different power mode
- Supports COM, CAN, USB, and GbE LAN
Introduction
The CEM310, a COM Express Type 10 Mini module, supports Intel® Atom® x5 and x7 processors (codename: Apollo Lake) in a board size of 84mm x 55mm. It has 8GB of DDR3L onboard memory and an optional 64GB eMMC memory. The Intel® Atom®-based COM Express Type 10 Mini module comes with a variety of I/O and expansion options including four PCIe x1 lanes, one Gigabit LAN port with Intel® i210IT Ethernet controller, two USB 3.0, eight USB 2.0, two SATA-600, four digital I/O channels, HD Codec audio, one DDI, one LVDS, one LPC, one SPI, two serial TX/RX and one I2C to meet customer requirements. Aside from the rich I/O options, the CEM310 has a wide voltage input range of 4.75V to 20V to meet the varying voltage input requirements for automotive or transportation applications. In addition, it supports an extended operating temperature range from -20ºC to +70ºC or optional -40ºC to +85ºC to ensure stable and reliable operation in harsh environments. The CEM310 supports watchdog timer, hardware monitoring functions, SMBus as well as smart battery (optional).
