| CPU |
- LGA1151 9th/8th gen Intel® Core™ i7/i5/i3, Intel® Pentium® processors Gold/Celeron® processors (up to 65W)
|
| Chipset |
- Intel® H310
- Intel® Q370 (optional)
|
| System Memory |
- 2 x 260-pin DDR4-2666/2400 SO-DIMM, up to 64GB
|
| BIOS |
|
| COM |
- 1 x RS-232/422/485
- 1 x RS-232
|
| USB |
|
| Ethernet |
- 2 x 10/100/1000 Mbps (Intel® i211-AT & Intel® i219-V (LM))
|
| Display |
- 1 x DisplayPort++
- 1 x HDMI 1.4b (3840 x 2160 @30Hz)
- 1 x LVDS
- 1 x VGA (Wafer connector)
- 1 x eDP (optional)
|
| Digital I/O |
- 8-channel in/out programmed
|
| Audio |
|
| Storage |
- 2 x SATA-600
- 1 x mSATA
- 1 x M.2 Key M (22 x 42/22 x 60/22 x 80); supports NVMe
|
| Expansion |
- 1 x PCIe x4
- 1 x M.2 Key E (22 x 30)
- 1 x Full-size PCI Express Mini Card slot
|
| Others |
- Infineon SLB9665TT2.0 with TPM 2.0 compliant
|
| Battery |
|
| Power Input |
- DC Power Jack connector
- ATX 2 x 2-pin vertical/horizontal(optional) connector support 12V, 19V to 24 VDC input
- AT Auto Power On function supported
|
| Watchdog Timer |
- 255 levels, 1 to 255 sec.
|
| Hardware Monitoring |
|
| Operating Temperature |
- 0°C to +60°C (+32°F to +140°F)
|
| Relative Humidity |
- 10% to 95% relative humidity, non-condensing
|
| Dimensions |
|
| Board Thickness |
|
| Certifications |
|
