| CPU |
- LGA1700 socket 13th/12th gen Intel® Core™ i7/i5/i3, Celeron® processor (TDP up to 15W)
|
| Chipset |
|
| System Memory |
- 2 x 262-pin dual-channel DDR5-4800 SO-DIMM, up to 64GB
|
| BIOS |
|
| COM |
|
| USB |
- 2 x USB 3.2 in USB Type-A
- 2 x USB 3.2 in USB Type C, same port supports DP Alt mode
- 2 x USB 2.0
|
| Ethernet |
- 1 x 10/100/1000 Mbps Ethernet with Intel® I219
- 2 x 10/100/1000/2500 Mbps Ethernet with Intel® I226-V
|
| Display |
- 2 x HDMI 1.4
- 1 x eDP
- 2 x DisplayPort in USB Type C (DP Alt Mode)
|
| Digital I/O |
- 8-channel in/out programmed
|
| Audio |
- 1 x M.2 Key M 2280 (PCIe x4)
|
| Storage |
|
| Expansion |
- 1 x M.2 Key E 2230 (PCIe x1/USB 2.0)
- 1 x M.2 Key B 3042/3050 (PCIe x1/USB 3.2 Gen2/USB 2.0)
- 1 x SIM connector via pin header
|
| Others |
|
| Battery |
|
| Power Input |
- 2 x 2-pin connector
- +12V DC-in
- AT Auto Power On function supported
|
| Power Requirements |
|
| Watchdog Timer |
- 255 levels, 1 to 255 sec.
|
| Hardware Monitoring |
|
| Operating Temperature |
- Fan: 0°C to +60°C (+32°F to +140°F)
|
| Relative Humidity |
- 10% to 95% relative humidity, non-condensing
|
| Dimensions |
|
| Board Thickness |
|
| Certifications |
|
| Industrial Chassis |
|
