| CPU |
- Intel® Core™/Pentium®/Celeron® or Intel Atom® processors x7000 series
|
| Chipset |
|
| System Memory |
- LPDDR5-4800 with IBECC support, up to 16GB
|
| BIOS |
|
| COM |
|
| USB |
- 2 x USB 3.2 Gen1
- 6 x USB 2.0
|
| Ethernet |
- 2 x 10/100/1000/2500 Mbps Ethernet (Intel® I226)
|
| Display |
- 1 x LVDS; 18/24-bit single/dual-channel (optional eDP 1.4b)
- 1 x HDMI
- 1 x DisplayPort/HDMI
|
| CAN |
|
| I2C |
|
| SPI |
|
| GPIO |
- 7-CH in and 7-CH out (shared with Fan & HDA)
|
| GSPI |
- 1 x GSPI (optional 1 x eSPI)
|
| Audio |
- HDA link interface to baseboard for codec
|
| Storage |
- eMMC5.1, up to 128GB
- 1 x SATA Gen3
|
| SMBus |
|
| Expansion |
- 3 x PCIe x1 (default)
- 1 x PCIe x4 or 4 x PCIe x1 (optional)
|
| Smart Battery |
|
| Hardware Monitoring |
|
| Others |
|
| Battery |
|
| Power Requirement |
- ATX: Vin, VSB; AT: Vin
- Vin: 4.75 to 5.25V, RTC battery: 2.0V to 3.3V
|
| Operating Temperature |
- Industrial: -40°C to +85°C (-40°F to +185°F) with a system thermal solution
- Standard: 0°C to +60°C (32°F to +140°F) with operation
|
| Relative Humidity |
- 10% to 95% relative humidity, non-condensing
|
| Dimensions |
|
| Board Thickness |
|
| Vibration |
|
| Certifications |
|
