| CPU |
- NXP i.MX 8M Plus 1.8GHz SoC with Quad A53
|
| AI Accelerator |
|
| System Memory |
|
| OS |
- Yocto 3.3, Linux Kernel 5.10.35
|
| COM |
- 1 x DB9 for RS-232 (Tx/Rx)
- 1 x DB9 for RS-232/RS-485 (Tx/Rx)
|
| USB |
- 2 x USB 2.0
- 4 x USB 3.2 Gen1 Type A
|
| Ethernet |
- 2 x GbE LAN (SCM186 support 1 x GbE LAN)
|
| Display |
- 1 x Dual-channel 24-bit LVDS
- 1 x HDMI
- 1 x DisplayPort (not supported on SCM186)
|
| SPI |
|
| QSPI |
|
| I2C |
|
| GPIO |
|
| CAN |
|
| Camera Input |
|
| Audio |
|
| Storage |
- 1 x Micro SD slot
- 1 x 8GB eMMC
- 1 x SATA for SATA III (not supported on SCM186)
- 1 x SATA Power (not supported on SCM186)
- 1 x Micro SD slot
|
| Expansion |
- 1 x PCIe x4 slot (SCM186 supports PCIe Gen3 x1)
- 1 x SIM card slot
- 1 x M.2 Key B 3052 slot for 5G Module
|
| Others |
- 1 x TPM 2.0 (option, none in default)
- 1 x OS Flash
|
| Battery |
|
| Power Requirement |
- 1 x Lockable DC jack (12V-24V)
|
| Operating Temperature |
- 0°C to +70°C (-32°F to +158°F)
|
| Relative Humidity |
- 10% - 95%, non-condensing
|
| Dimensions |
- 146 x 102 mm (approx. 5.75" x 4.02")
|
| Board Thickness |
|
| Certifications |
|
