CPU |
- Intel® Xeon® or 9th/8th gen Intel® Core™ processor (Coffee Lake & Coffee Lake Refresh)
|
Chipset |
|
System Memory |
- Dual-channel DDR4-2666 SO-DIMM, up to 64GB (or 96GB by request)
|
BIOS |
|
Serial |
|
USB |
- 4 x USB 3.2 Gen 2
- 8 x USB 2.0
|
Ethernet |
- 1 x 10/100/1000 Mbps Ethernet (Intel® I219-LM)
|
Display |
- 1 x LVDS; 18/24-bit single/dual channel (default), optional with eDP 1.4: 4096 x 2304 @60Hz
- 1 x VGA; 1920 x 1200 @60Hz (default)
- 2 x DDI (DisplayPort 1.2: 4096 x 2304 @60Hz/HDMI 1.4: 4096 x 2160 @30/24Hz)
|
GPIO |
- 4-CH in & 4-CH out (SDIO optional)
|
Audio |
- HD link interface to baseboard for Codec
|
Storage |
- 4 x SATA Gen3 with RAID 0/1/5/10
|
Expansion |
- 1 x PCIe x16 Gen3
- 8 x PCIe x1 Gen3
|
Others |
|
Battery |
|
Power Input |
|
Watchdog Timer |
- 65536 levels, 0 to 65535 sec.
|
Hardware Monitoring |
|
Operating Temperature |
- -40°C to +85°C (-40°F to +185°F) with system thermal solution (operation with heatsink and fan)
|
Relative Humidity |
- 10% - 95% relative humidity, non-condensing
|
Vibration |
|
Dimensions |
|
Board Thickness |
|
Certifications |
|
