Rugged Embedded Solution (Wide Temperature)
Introduction
Axiomtek provides a wide array of fanless and extended
temperature embedded products from board level products
to whole systems (eBOX). To improve the system reliability
for extreme temperature environments and to extend the
MTBF, Axiomtek's embedded solutions have adapted a
fanless system by improving the board design and
enhancing quality screening during production. Axiomtek's
fanless & extended temperature embedded solutions supply
stable and reliable hardware platform performance and are
designed particularly to meet more rigorous industrial
applications.
Fanless Embedded Systems (eBOX Series)
Axiomtek has developed a series of durable and application-ready embedded box computers, the eBOX series. The fanless design and excellent thermal solution support the highly reliable eBOX series to operate without noise and reliably in critical environments at temperature from -10°C to +50°C or above (-20°C to +60°C). Axiomtek's eBOX series is suitable for a wide range of industrial applications in the market, such as POS, kiosk, ATM, thin servers, building automation, project screens for department stores and supermarkets, tour bus displays, gaming, and more.
All Axiomtek's eBOX system products furnish customers with all users' needs like powerful computing capability, fanless operation, wide temperature operating range, low power use, extreme reliability and ruggedness, scalability, flexible I/O configuration and long product life support. Additionally, the eBOX series supports most operating systems, including Windows® CE.NET, Windows® XP Embedded and Embedded Linux.
 |
| Model | Description | Extended Temperature |
|---|---|---|
| eBOX310-830-FL | Fanless Embedded System with Intel® Core™2 Duo processor up to 2.33 GHz and Intel® 945GME+ICH7M Chipset for Vehicle PC | 0 ~ 50°C (w/ HDD) |
| eBOX646-FL | Fanless Embedded System with AMD LX800 500MHz Processor | -10 ~ 50°C (w/ W.T. CF) |
| eBOX647-FL | Fanless Embedded System with VIA Processor up to 1.5 GHz | 0 ~ 50°C |
| eBOX510-820-FL | Fanless Embedded System with Intel® Atom™ Processor up to 1.6 GHz and Intel® US15W Chipset | 0 ~ 50°C |
| eBOX530-820-FL | Ultra-compact, Fanless Embedded System with Intel® Atom™ Processor up to 1.6 GHz and Intel® US15W Chipset | 0 ~ 45°C (w/ W.T. HDD) |
| eBOX511-820-FL | Fanless Embedded System with Intel® Atom™ Processor Z510/ Z530 up to 1.6 GHz and Wide Range DC-int | 0 ~ 50°C (w/ W.T. CF) |
| eBOX531-820-FL | Fanless Embedded System with Intel® Atom™ Processor Z510/Z530 up to 1.6 GHz and Wide Range DC-int | 0 ~ 45°C (w/ W.T. HDD) |
| eBOX622-831-FL | Fanless Embedded System with Intel® Atom™ N270 1.6 GHz Processor, Intel® 945GSE + ICH7M Chipset and 6 RS-232 | -10 ~ 50°C (w/ W.T. HDD) |
| eBOX620-800-FL | Fanless Embedded System with Intel® Atom™ Processor N450/ D510 1.66 GHz and Dual Display Support (optional) | -10 ~ 55°C (w/ W.T. HDD) |
| eBOX620-823-FL | Fanless Embedded System with Intel® Atom™ Processor Z510/520PT and Intel® SCH US15WPT Chipset | -20 ~ 70°C (w/ W.T. HDD) |
| eBOX620-831-FL | Fanless Embedded System with Intel® Atom™ N270 1.6 GHz Processor and Intel® 945GSE+ICH7M Chipset | 0 ~ 50°C (w/ W.T. HDD) |
| eBOX621-831-FL | Fanless Embedded System with Intel® Atom™ Processor N270 1.6 GHz and 9 ~ 34VDC Input | -10 ~ 50°C (w/ W.T. HDD) |
| eBOX630-850-FL | Fanless Embedded System with Intel® Core™2 Duo Processor up to 2.66 GHz and Optional DualView Support | 0 ~ 45°C (w/ W.T. HDD) |
| eBOX630-821-FL | Fanless Embedded System with Intel® Pentium® M Processor | 0 ~ 50°C (w/ W.T. HDD) |
| eBOX630-830-FL | Fanless Embedded System with Intel® Core™2 Duo Processor | 0 ~ 50°C (w/ W.T. HDD) |
| eBOX640-822-FL | Fanless Embedded System with Intel® Pentium® M Processor up to 2 GHz | -10 ~ 50 °C (w/ W.T. HDD) |
| eBOX746A-FL | Fanless Embedded System with VIA Processor up to 1.5GHz | -10 ~ 55°C (w/ W.T. HDD) |
| eBOX745-FL500 | Fanless Embedded System with AMD LX800 500MHz Processor | -20 ~ 50°C (w/ W.T. HDD) |
| eBOX639-840-FL | Fanless Embedded System with Intel® Core™2 Duo Processor, PCI and PCIe x16 Slots | -10 ~ 40°C (w/ W.T. HDD) |
| eBOX639-836-FL | Fanless Embedded System with Intel® Atom™ N270 1.6 GHz Processor, Intel® 945GSE+ICH7M Chipset and 2 PCI Slots | -10 ~ 50 °C (w/ W.T. HDD) |
| eBOX639-822-FL | Fanless Embedded System with Intel® Pentium® M Processor up to 2 GHz and 2 PCI Slots | 10 ~ 50 °C (w/ W.T. HDD) |
| eBOX830-822-FL | Fanless Embedded System with Intel® Pentium® M Processor up to 2.0 GHz and PCI Slot | 0 ~ 45°C (w/ W.T. HDD) |
| eBOX830-831-FL | Fanless Embedded System with Intel® Core™2 Duo Processor up to 1.5 GHz and PCI Slot | 0 ~ 45°C (w/ W.T. HDD) |
- Wide Operating Temperature SBCs
Integrated with the proper components and passing a rigorous production screenings, Axiomtek' s SBC's which are utilized in the eBOX's and are guaranteed to work well in wider temperature range environments, from -25°C to + 70°C. Axiomtek's extended temperature embedded boards employ low-power core logic computing engines: from AMD LX800, VIA Eden V4/V7, to ULV/LV Intel® Pentium® M/ Celeron® M to Intel® Atom™ for x86 architecture. Axiomtek has the right tools for any application. Cooling fans usually have an MTBF of approximately 20,000 hours, which is not acceptable for most applications. Axiomtek's SBC's provide the answer: an onboard low power consumption CPU that eliminates fan usage for better system reliability.
| Model | Description | Extended Temperature |
|---|---|---|
| Intel® Atom™ N270 3.5" Embedded SBC with Intel® 945GSE + ICH7M Chipset, LVDS/VGA, DualView, 4 COM and Single LAN | -20 ~ 70°C | |
| Intel® Atom™ Embedded SBC with Intel® 945GSE+ICH7M Chipset, CRT/LVDS, DualView, 6 COM and Dual LANs | -25 ~ 70°C | |
| Intel® Atom™ Z510PT 3.5" Embedded SBC with Intel® SCH US15WPT Chipset, VGA/LVDS, Dual LANs and PCI Express Mini Card | -40 ~ 85°C | |
| Intel® Atom™ Embedded SBC with Intel® System Control Hub US15W PT Chipset, VGA/LVDS, DualView and Mini Card | -40 ~ 85 °C | |
| AMD LX Embedded SBC with Dual LANs, 4 COM and 4 USB 2.0 | -40 ~ 85°C | |
| SBC84621 | AMD LX Embedded SBC with Dual LANs, 4 COM and 4 USB 2.0 | -40 ~ 85°C |
| AMD LX Embedded SBC with Dual LANs, 4 COM and 4 USB 2.0 | -25 ~ 70°C | |
| Intel® Atom™ N455/ D425/ D525 Embedded SBC with Intel® ICH8M Chipset, LVDS VGA, Dual LANs & Audio | -20 ~ 70 °C | |
| Intel® Atom™ N450/ D410/ D510 3.5" Embedded SBC with Intel® ICH8M Chipset, LVDS/VGA, Dual LANs and Audio | -20 ~ 70°C | |
| AMD Geode™ LX Family ETX V3.0 SoM with Multiple I/O Features | -40 ~ 85 °C | |
| AMD LX PC/104 CPU Module with CRT/LCD, USB DoM and PC/104-Plus Expansion | -40 ~ 85 °C | |
| AX12270 | VIA V4 PC/104 CPU Module with DualView, Onboard Memory and PC/104-Plus Expansion | -25 ~ 70°C |
Advantages
-
Reliability: Axiomtek's fanless and extended temperature embedded solutions can improve system reliability and stability in critical temperature environments and more rigorous industrial applications.
Applications: Axiomtek's eBOX series is suitable for a wide range of industrial applications in the market, such as POS, Kiosk, ATM, Thin Servers, diskless workstations, building automation, project screens for department stores and supermarkets, tour bus displays, and much more.
Embedded OS: Axiomtek's series of fanless and extended temperature products can be bundled with embedded OS solutions: Microsoft Windows® and Embedded Linux family-based products and services including Windows® CE.NET, Windows® XP Embedded and Embedded Linux.
Expansion: Axiomtek's fanless and extended temperature products support CompactFlash™ and 2.5" HDD drive bays.
Watchdog Timer: the system will automatically reset to reduce the need for maintenance.
