What type of module is the CEM322? + The CEM322 is a COM Express Type 6 compact module designed for high-performance and mission-critical applications.
Which processors are supported by the CEM322? + The module supports Intel® Pentium®, Celeron®, and Atom® x6000 series processors from Intel Corporation, providing energy-efficient performance for a wide range of workloads.
What memory options are available for the CEM322? + The CEM322 supports up to 32GB of dual-channel DDR4-3200 SO-DIMM memory, enabling seamless multitasking and fast data processing for demanding applications.
Which graphics capabilities does the CEM322 offer? + The module features Intel® Gen11 integrated graphics engines and supports triple simultaneous displays via two DDI ports and one LVDS output.
What I/O and connectivity options are available on the CEM322? + The CEM322 provides five PCIe x1 slots, six optional PCIe x1 lanes, two USB 3.2 Gen1 ports, eight USB 2.0 ports, one 2.5GbE LAN port with Intel® I226 support, two SATA Gen3 ports, HD Codec audio, one LPC, one SPI, two TX/RX, and a 4-channel GPIO, as well as optional eMMC 5.1 storage of up to 64GB.
Can the CEM322 be integrated into different system types? + Yes, the module supports ATX (+12V, +5VSB) and AT (+12V) power configurations, allowing flexible integration into a variety of carrier boards and system designs.
What operating temperature ranges does the CEM322 support? + The CEM322 operates in industrial-grade environments from -40°C to +85°C and in standard-grade environments from 0°C to +60°C, ensuring reliable operation under harsh conditions.
What management and security features does the CEM322 include? + The module comes with AXEAPI 3.0 support for hardware monitoring, watchdog timers, and DIO control, and it also includes TPM 2.0, delivering robust security and consistent system performance.
What industries is the CEM322 suitable for? + The CEM322 is ideal for medical, industrial automation, defense, and other mission-critical applications, providing flexibility, reliability, and long-term support.
How does the CEM322 support system customization and upgrades? + The module offers BOM customization options and in-house firmware support, allowing customers to tailor the CEM322 to specific project requirements and perform efficient updates without sacrificing performance.
